Pen-type Hardness Tester
Pen-type Hardness Tester Pen-type Hardness Tester Pen-type Hardness Tester Pen-type Hardness Tester

Pen-type Hardness Tester

Product ID : TH100
Product Tags :
Product Description
Features: 1, Intelligent operation: easy operation with several buttons, magnitude and Rockwell values displayed 2, Industrial bright LED display: good performance of OLED display, even in the sunshine 3, Accurate measurement value: high accuracy shown value error ±0.5%(HLD=800), showing the value of repeatability of 0.8% 4, Supports a variety of hardness standards: HL, HV, HRA, HRC, HRB, HB, HV, HS 5, Large capacity of data storage: Mass storage hitherto unknow, leading the technology trend. The retention of data to measurement the hardness of 300 groups. 6, Support “forged steel” material: hardness values can be preset, limit, beyond the range of automatic alarm, convenient batch testing needs. 7, Working hours: 10 hours Specification: 1, Testing direction: Highly accurate in any impact direction 2, Testing range: (170-960)HLD; (17.9-69.5)HRC; (19-683)HB; (80-1042)HV; (30.6-102.6)HS; (59.1-88)HRA; (13.5-101.7)HRB 3, Hardness standards: HL, HV, HRA, HRC, HRB, HB, HV, HS 4, Accuracy: HLD: ±0.5%(800HLD) 5, Repeatability Value: HLD: 0.8%(800HLD) 6, Resolution: 128*64 OLED display 7, Dimensions: 148*40*30mm 8, Power: Rechargeable Lithium battery 9, Working hours: About 10 hours 10, Work conditions Operation Temperature: 10-50c Storage temperature: -30c-60c Humidity: 90% max
