2, Variety of detecting methods, and data would be automatically saved if machines is powered off
3, Flat keyboard design, easy to operate
4, Reflect the leak point more clearly by voltage-controlled oscillator frequency technology.
5, Small size, light weight, easy to carry, much more suitable for outdoor usage.
Specifications
|
Model |
FJ-6 |
|
|
Transmitter |
Capacity |
0-25W |
|
Resistance |
5-500Ώ Auto adjustment |
|
|
Launch Distance |
0.03-5km |
|
|
Pipe locator |
Sensitivity |
-65db |
|
Deviation |
≤5cm |
|
|
Testing Depth |
≤6m |
|
|
Leak Detector |
Accuracy |
≥0.5㎜2 |
|
Deviation |
≤5cm |
|
|
Size |
Transmitter: 276mm×227mm×98mm |
|
|
Pipe locator: 165mm×110mm×68mm |
||
|
Leak Detector: 165mm×110mm×68mm |
||
|
Weight |
Transmitte: 3.0kg |
|
|
Pipe locator: 0.9kg (Battery included) |
||
|
Leak Detector: 0.9kg (Battery included) |
||
|
Working Power |
Transmitte: 12v |
|
|
Pipe locator: 9.6v |
||
|
Leak Detector: 9.6v |
||
|
Working Temperature |
-10℃~50℃ |
|
|
Testing Accuracy |
≤0.1% |
|
